Metinox Overseas is one of the most reputed manufacturers and suppliers of flanges and also supply their products to the national and international market. Metinox Overseas manufacture all types of flanges, including Lap Joint Flange. We have been a part of this industry for years.
Flate Face Lap Joint Flanges, ANSI B16.5 Lap Joint Flanges, Lap Joint Flanges Stockist, LJ Flanges, LJ Flanges Exporter, High Quality Lap Joint Flanges Supplier, Raised Face Lap Joint Flanges, High Pressure Lap Joint Flanges, Lap Joint Flanges Manufacturer in Mumbai India
These flanges are also available in different types, which are different class lap joints. The most prominent forms of these LJ flanges are LJ, WNRF, threaded, spectacles, reducing, SWRF, etc. The coating done on these Lap Joint Flanges is rustproof paint, oil paint, hot and cold galvanization, and other types of coating are done on these flanges. These have a high level of mechanical strength.
Titanium Lap Joint Flanges, Alloy Steel Lap Joint Flanges, Carbon Steel Lap Joint Flanges, Copper Nickel Lap Joint Flanges Dealer, Duplex/Super Duplex Steel Lap Joint Flanges, Stainless Steel Lap Joint Flanges, Nickel Alloy Lap Joint Flanges, 2500# Class Lap Joint Flanges, 1500 lbs Lap Joint Flanges, High Pressure Lap Joint Flanges Exporter in Mumbai.
These Lap Joint Flanges are available in different grades as required by the customers. These flanges contain brass, bronze, titanium, nickel, etc. The face of these flanges is raised face, ring joint, flat face. These lap joint flanges are used in the carbon steel piping or low alloy steel piping system. This lap joint needs a lap joint stub to attach to the piping system.
The advantages of these Lap Joint Flanges are, these LJ flanges can easily move around the pipes. These LJ flanges are less prone to contact with fluids, so their durability increases. Thus for the pipes which corrode easily, the lap joint may be salvaged for reuse. The pressure holding capacity of these joints is very low, but it is better than slip-on flanges. And, the bolt holes can be aligned with the matching flanges after the welding. These flanges have good elasticity and welding ability and can easily be welded.
These Lap Joint Flanges are prominently used by chemical industries, petrochemical industries, natural gas industries, oil industries, pulp industries, paper industries, off-shore industries, mining industries, engineering company, heat exchangers, gas industries, chemicals reservoirs, pharmacy surgical industries, nuclear thermal industries and many more.
These flanges clear many tests with flying colors before rolling out to clients. Some of the most common ones are the raw material test, mechanical test, and many other types of tests on these flanges. We package these flanges in wooden boxes to maintain their safety while in transport.s
Read More
Types of Lap Joint Flanges
Stainless Steel Lap Joint Flanges
Stainless Steel 304 Lap Joint Flanges, ASTM A182 F304 Lap Joint Flanges Manufacturer, SS grade 321 Lap Joint Flanges Exporter, SS F304L Lap Joint Flanges Dealer, SUS 316 Lap Joint Flanges, F310 SS LJ Flanges, 310S Stainless Steel Lap Joint Raised Face Flanges, ASME SA182 SS 317L LJ Flanges in Mumbai, India.
Carbon Steel Lap Joint Flanges
Carbon Steel Lap Joint Flanges Flanges, ASTM A105 CS Lap Joint Flanges Manufacturer, Carbon Steel Lap Joint Flanges Exporter, Carbon Steel Lap Joint Flanges Dealer, High Yeild Lap Joint Flanges, carbon Steel Lap Joint Flanges, LTCS Lap Joint Raised Face Flanges, CS LF2 LJ Flanges in Mumbai, India.
High Nickel Lap Joint Flanges
High Nickel Alloy Lap Joint Flanges, ASTM B564 Nickel Alloy 200 Lap Joint Flanges Manufacturer, Hastelloy C22 Lap Joint Flanges Exporter, Monel 400 Lap Joint Flanges Dealer, Inconel 600 Lap Joint Flanges, Titanium LJ Flanges, ASME SB564 Incoloy 800 Lap Joint Flanges in Mumbai, India.
Alloy Steel Lap Joint Flanges
Chrome Moly Lap Joint Flanges, ASTM A182 Alloy Steel Lap Joint Flanges Manufacturer, Chrome Moly F1 Lap Joint Flanges Exporter, Alloy Steel F5 Lap Joint Flanges Dealer, Alloy Steel F11 Lap Joint Flanges, Alloy Steel LJ Flanges, Ti Lap Joint Flanges, ASME SA182 Alloy Steel Lap Joint Flanges in Mumbai, India.
Specification of Lap Joint Flanges
Specifications : ASTM A182 / B564 / A105 / A350 / A694 / B381.
Dimensions : ANSI/ASME SB16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size : 1/2" (15 NB) to 48" (1200NB)
Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Lap Joint Flanges Dimension(in mm)
| Nominal Bore | Dia. (D) | Thick. (E) | Dia. (B) | Dia. (A) | Height (H) | Nbr | Holes | Dia. (C) |
| 1/2" | 90 | 11.2 | 30 | 22.9 | 16 | 4 | 15.87 | 60.3 |
| 3/4" | 100 | 12.7 | 38 | 28.2 | 16 | 4 | 15.87 | 69.9 |
| 1" | 110 | 14.3 | 49 | 34.9 | 17 | 4 | 15.87 | 79.4 |
| 1 1/4" | 115 | 15.9 | 59 | 43.7 | 21 | 4 | 15.87 | 88.9 |
| 1 1/2" | 125 | 17.5 | 65 | 50.0 | 22 | 4 | 15.87 | 98.4 |
| 2" | 150 | 20.7 | 78 | 62.5 | 25 | 4 | 19.05 | 120.7 |
| 2 1/2" | 180 | 22.3 | 90 | 75.4 | 29 | 4 | 19.05 | 139.7 |
| 3" | 190 | 23.9 | 108 | 91.4 | 30 | 4 | 19.05 | 152.4 |
| 3 1/2" | 215 | 23.9 | 122 | 104.1 | 32 | 8 | 19.05 | 177.8 |
| 4" | 230 | 23.9 | 135 | 116.8 | 33 | 8 | 19.05 | 190.5 |
| 5" | 255 | 23.9 | 164 | 144.4 | 36 | 8 | 22.22 | 215.9 |
| 6" | 280 | 25.4 | 192 | 171.4 | 40 | 8 | 22.22 | 241.3 |
| 8" | 345 | 28.6 | 246 | 222.2 | 44 | 8 | 22.22 | 298.5 |
| 10" | 405 | 30.2 | 305 | 277.4 | 49 | 12 | 25.40 | 362.0 |
| 12" | 485 | 31.8 | 365 | 328.2 | 56 | 12 | 25.40 | 431.8 |
| 14" | 535 | 35.0 | 400 | 360.2 | 79 | 12 | 28.57 | 476.3 |
| 16" | 595 | 36.6 | 457 | 411.2 | 87 | 16 | 28.57 | 539.8 |
| 18" | 635 | 39.7 | 505 | 462.3 | 97 | 16 | 31.75 | 577.9 |
| 20" | 700 | 42.9 | 559 | 514.4 | 103 | 20 | 31.75 | 635.0 |
| 24" | 815 | 47.7 | 663 | 616.0 | 111 | 20 | 34.92 | 749.3 |
