- Product:
- Grade:
- ASTM:
- UNS:
- DIN:
- Stainless Steel Welded Pipes
- 316/316L
- A312
- S31600/ S31603
- 1.4401/1.4404
SS 316 Welded Pipes, SS 316L Welded Pipes both are produced and supply by the Metinox overseas in both the national and international markets. We provide these pipes in various thicknesses, sizes, and dimensions. This grade of pipes is extremely corrosion resistant and has a very long life. The pipes show excellent features and properties and are high in demand in various industries.
ASTM A312 Stainless Steel TP316L Welded Pipe, Stainless Steel S31600 Welded Pipes, Stainless Steel 1.4401 Welded Pipe, SS 316 / 316L Welded Pipes, SS 1.4436 Welded Pipes, TP316 Stainless Steel Welded Pipe, SUS 316 Welded Pipes, ASME SA312 TP316L Stainless Steel Welded Pipes Supplier in Mumbai India
The specification of SS 316 Welded Pipes are ASTM A312/ASTM SA 312, the outer diameter is 6.35mm O.D to 114.3 mm O.D, the thickness is 0.8 mm to 12.7mm, the length is up to 26 meters, with the beveled and plain end. The characteristics of these pipes are it has excellent pitting and corrosion resistance; exceptional resistance in acid and hand water areas, rapture and tensile strength, excellent formability and weldability and also it has higher creep resistance.All types of SS 316 Welded Pipes have excellent features and benefit therefore used in various industries. The SS 316L grade also have high tensile strength and yield strength.
Stainless Steel 316 Cold Drawn Pipes, Stainless Steel 316L Welded Industrial Pipe, 316/316L Stainless Steel Welded Pipe Dealer, Stainless Steel 316 Welded Pipes, SS 316L ERW Pipes, Stainless Steel 316L Welded Piping, Stainless Steel TP316/316L Welded Round Pipes, SS 316 Welded Pipes Exporter in Mumbai.
The advantages of welded pipes are they are permanently leak-proof. The strength of the system of pipe increases by the continuity between the pipe and the fitting. By the system, smooth furnace and gradual direction change the pressure losses and the turbulence is reduced. As compared to other connecting methods the welding system uses space more efficiently. All this benefits made the SS 316 grades pipes durable and a popular grade of pipes.
The SS 316 Welded Pipes, SS 316L Welded Pipes are used in various applications such as paper and pulp industry, power plant, water supply systems, heating, general-purpose applications, plumbing, chemical industry, oil, and gas industry, fabrication industry, and food processing industry.
Several tests are also performed to check the quality of the product and proper documentation is provided with the delivery of the product. Packing is done usually in wooden cases/ pallets to assure the harmless and safer shipping. The pipes are covered with environmental polybag to protect it from outside atmospheric conditions and make it an excellent rust proof product.
Read More
Types of Stainless Steel 316 / 316L Welded Pipes
Welded Round Pipe
ASTM A312 TP316 Welded Round Pipes Supplier, SS S31600 Welded Round Pipes Exporter, SS 1.4401 Welded Round Pipes Dealer, SUS 316 Welded Round Pipes, ASME SA312 SS 316 Welded Round Pipes in Mumbai, India.
Welded Polish Pipe
ASTM A312 TP316L Welded Polish Pipes Supplier, SS S31603 Welded Polish Pipes Exporter, SS 1.4404 Welded Polish Pipes Dealer, SUS 316L Polish Welded Pipes, ASME SA312 SS 316L Welded Polish Pipes in Mumbai, India.
Specification of Stainless Steel 316 / 316L Welded Pipes
Specifications : ASTM A312 / ASME SA312
Outside Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24" NB available Ex-stock, OD Size available Ex-stock
Thickness : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Size : 1/2" NB - 24" NB
Type : Welded
Form: Round Pipes, Square Pipes, Rectangular Pipes.
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
Equivalent Grades of Stainless Steel 316 / 316L Welded Pipes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | - | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Chemical Composition of Stainless Steel 316 / 316L Welded Pipes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 | 67.845 min |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 | 68.89 min |
ASME SA 312 SS 316 / 316L Welded Pipe Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
